Fired Up Since '63
When Gibson hired famed automotive designer Ray Dietrich to create a radical new solid body guitar, Rock 'n Roll history ensued. With its offset shape, neck-through construction and scorching mini-humbuckers, the '63 Firebird V became an instant classic. Custom Shop is proud to present this exacting replica of a vintage original, which uses authentic contours, dimensions and construction methods for an incredible ownership and playing experience.
Body
Body Shape
Designer
Body Material
9-ply Mahogany/Walnut Neck-Through
Binding
Fingerboard 1-Ply Cream
Weight Relief
None
Finish
Nitrocellulose Lacquer VOS (Vintage Patina)
Neck
Material
9-ply Mahogany/Walnut Neck-Through
Profile
Authentic '63 Medium C-Shape
Scale Length
24.75" / 628.65mm
Fingerboard Material
Indian Rosewood, Hide Glue Fit
Fingerboard Radius
12"
Number Of Frets
22
Frets
Authentic Medium-Jumbo
Nut Material
Nylon
Nut Width
1.69" / 42.85mm
End of Board Width
2.24" / 56.89mm
Inlays
Aged Cellulose Nitrate Trapezoid
Joint
Neck-Through Construction
Hardware
Finish
Nickel
Tuner Plating
Nickel
Bridge
ABR-1
Saddle Material
Nickel-plated Brass
Tailpiece
Maestro Vibrola
Tuning Machines
Deluxe Banjo Tuners
Pickguard
3-Ply White/Black/White Firebird Hot-stamped
TrussRod
2-way Adjustable
Truss Rod Cover
Black 1-Ply Gibson Hot-stamped
Control Knobs
Gold Top Hats w/ Silver Inserts
Switch Tip
Cream
Control Covers
Black
Strap Buttons
Aluminum
Pickup Covers
Nickel
Electronics
Neck Pickup
Firebird Alnico V
Bridge Pickup
Firebird Alnico V
Controls
2 500K CTS Volume Pots, 2 500K CTS Tone Pots, Hand-Wired Harness
Pickup Selector
3-Way Switchcraft
Output Jack
Switchcraft
Miscellaneous
Strings
.010, .013, .017, .026, .036, .046
Case
Black/Yellow Custom Shop Hardshell
Accessories
Certificate of Authenticity
